dB Technologies FIFTY SUB

dB Technologies FIFTY SUB

This cabinet has been designed to perfectly pair with Fifty tops in ground stacked configurations, sharing the same design, as well as same DSP and Class-d 1600W RMS power amplifier.

dB Technologies always recommends to stack 1x or 2x Fifty tops over 2x Fifty sub for an optimal performance.

Technical Data

• Speaker Type: Active Subwoofer
• Frequency Response: [-6dB]38 Hz - Xover Frequency
• Max SPL: 135.4 dB
• LF: 1x 18"
• LF Voice Coil4"
• Amp Class: Class-D
• Peak Power: 3200 W
• RMS Power: 1600 W
• Cooling: Passive Convection
• Controller: DSP 32 bit
• AD/DA Converter24bit/96kHz
• Signal Input: 1 x XLR female
• Signal Out: 1 x XLR male
• USB connector: Type B - Data Service
• Controls: 1 rotary encoder (Preset)
• Power Socket: 1xPowerCon TRUE1 Mains, 1xPowerCon TRUE1 Link
• Housing: Plywood
• Grille: Full metal grille
• Rigging point: Flyable with accessories
• Handles: 2x side
• Width: 500 mm
• Height: 750 mm
• Depth: 600 mm
• Weight: 42Kg
